Sockel: 1200
Codename: Rocket Lake-S
TDP: 125 Watt
Anzahl Prozessorkerne: 8
Anzahl Threads: 16
Taktfrequenz: 8x 3500 MHz (Turbo-Modus bis 5300 MHz)
Level 3 Cache: 16 MB
Speicherkontroller: DDR4-3200 MHz
Dual-Channel
PCIe-Lanes: 20x PCIe 4.0
integrierter Grafik-Prozessor: GPU Type: Intel UHD 750
iGPU-Einheiten: 32EU
iGPU-Shader: 256
Base frequency (MHz): 350
Maximum frequency (MHz): 1300
iGPU-Interface: HDMI 2.0b (4096x2160@60Hz), DisplayPort 1.4a (5120x3200@60Hz), eDP (5120x3200@60Hz)
GPU-Features: DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan 1.0, Quick Sync Video, InTru 3D, Clear Video HD, 3x Display Support, H.265 encode/​decode, VP9 encode/​decode, AV1 decode, HDCP 2.3
Fertigung: 14 nm+++
geeignete Board-Chipsätze: B460, B560, H410 H470, H510, H570, Q470, W480, Z490, Z590
Features:
DL Boost, Thermal Velocity Boost (5.30GHz), Turbo Boost Max 3.0 (5.20GHz), Turbo Boost 2.0 (5.10GHz), vPro, Hyper-Threading, VT-x, VT-d, VT-x EPT, Intel 64, SSE4.1, SSE4.2, AVX, AVX2, AVX-512, Idle States, EIST, Thermal Monitoring, IPT, SIPP, GNA 2.0, AES-NI, Secure Key, OS Guard, TXT, XD Bit, Boot Guard, TDP-down (95W), TDP-down Frequenz (3.00GHz)
