Sockel: 1700
Codename: Raptor Lake-S
TDP: 125-181 Watt
Anzahl Prozessorkerne: 14 (6+8)
Anzahl Threads: 20 (12+8)
Basistakt: 3.50GHz (P-Core), 2.60GHz (E-Core)
Turbotakt: 5.10GHz
Freier Multiplikator: ja
L2-Cache: 20MB (6x 2MB + 8x 1MB)
Level 3 Cache: 24 MB
Speicherkontroller: Dual Channel DDR5-5600 (PC5-44800), DDR4-3200 (PC4-25600), 89.6GB/​s, max. 128GB
PCIe-Lanes: 16x PCIe 5.0, 4x PCIe 4.0
CPU-Funktionen: AES-NI, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.0, ISM, Idle States, Instruction Set 64bit (Intel 64), MBEC, OS Guard, SIPP, SSE4.1, SSE4.2, Secure Key, Speed Shift, TXT, Thermal Monitoring, Thread Director, VMD, VT-d, VT-rp, VT-x, VT-x EPT, XD Bit
Fertigung: Intel 7
geeignete Board-Chipsätze: B660, B760, H610, H670, H770, W680, Z690, Z790
integrierter Grafik-Prozessor: GPU Type: Intel UHD 770
iGPU-Einheiten: 32EU
iGPU-Shader: 256
Base frequency (MHz): 300
Maximum frequency (MHz): 1500
iGPU-Interface: DP 1.4a (7680x4320@60Hz), eDP 1.4b (5120x3200@120Hz), HDMI 2.1 (4096x2160@60Hz)
GPU-Features: 4x Display Support, 2x Multi-Format Codec Engine, Intel Clear Video HD, Intel Quick Sync Video, AV1 decode, H.265 encode/​decode, VP9 encode/​decode, HDCP 2.3, DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan 1.0
