Sockel: 1700
Codename: Raptor Lake-S
TDP: 125-181 Watt
Anzahl Prozessorkerne: 14 (6+8)
Anzahl Threads: 20 (12+8)
Basistakt: 3.50GHz (P-Core), 2.60GHz (E-Core)
Turbotakt: 5.30GHz (Turbo Boost 2.0), 5.30GHz (P-Core), 4.00GHz (E-Core)
Freier Multiplikator: ja
L2-Cache: 20MB (6x 2MB + 8x 1MB)
Level 3 Cache: 24 MB
Speicherkontroller: Dual Channel DDR5-5600 (PC5-44800), DDR4-3200 (PC4-25600), 89.6GB/​s, max. 192GB
PCIe-Lanes: 16x PCIe 5.0, 4x PCIe 4.0
CPU-Funktionen: AES-NI, AMT, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.0, Hardware Shield, Idle States, Instruction Set 64bit (Intel 64), ISM, MBEC, One-Click Recovery, OS Guard, RPE, Secure Key, SIPP, Speed Shift, SSE4.1, SSE4.2, TDT, Thermal Monitoring, Thread Director, Total Memory Encryption - Multi Key, TXT, VMD, VT-d, VT-rp, VT-x, VT-x EPT, XD Bit
Fertigung: Intel 7
geeignete Board-Chipsätze: B660, B760, H610, H670, H770, W680, Z690, Z790
integrierter Grafik-Prozessor: GPU Type: Intel UHD 770
iGPU-Einheiten: 32EU
iGPU-Shader: 256
Base frequency (MHz): 300
Maximum frequency (MHz): 1500
iGPU-Interface: DP 1.4a (7680x4320@60Hz), eDP 1.4b (5120x3200@120Hz), HDMI 2.1 (4096x2160@60Hz)
GPU-Features: 4x Display Support, 2x Multi-Format Codec Engine, Intel Clear Video HD, Intel Quick Sync Video, AV1 decode, H.265 encode/​decode, VP9 encode/​decode, HDCP 2.3, DirectX 12.1, OpenGL 4.5, OpenCL 3.0, Vulkan 1.0
