Sockel: 1700
Codename: Raptor Cove (P-Core) + Gracemont (E-Core)
TDP: 65W (Processor Base Power), 219W (Maximum Turbo Power)
Anzahl Prozessorkerne: 24 (8+16)
Anzahl Threads: 32 (16+16)
Basistakt: 2.00GHz (P-Core), 1.50GHz (E-Core)
Turbotakt: 5.80GHz (Thermal Velocity Boost), 5.60GHz (Turbo Boost Max 3.0), 5.40GHz (P-Core), 4.30GHz (E-Core)
Freier Multiplikator: nein
L2-Cache: 32MB (8x 2MB + 16x 1MB)
Level 3 Cache: 36 MB
Speicherkontroller: Dual Channel DDR5-5600 (PC5-44800), DDR4-3200 (PC4-25600), 89.6GB/​s, max. 192GB
PCIe-Lanes: 16x PCIe 5.0, 4x PCIe 4.0
CPU-Funktionen: AES-NI, AVX, AVX2, Boot Guard, CET, DL Boost, EIST, GNA 3.0, ISM, Idle States, Instruction Set 64bit (Intel 64), MBEC, OS Guard, SSE4.1, SSE4.2, Secure Key, Speed Shift, TVB, TXT, Thermal Monitoring, Thread Director, VMD, VT-d, VT-x, VT-x EPT, XD Bit
Fertigung: Intel 7
geeignete Board-Chipsätze: B660, B760, H610, H610E, H670, H770, Q670, Q670E, R680E, W680, Z690, Z790
Lieferumfang: mit CPU-Kühler (Intel Laminar RH1)
integrierter Grafik-Prozessor: n/a
