- Bis zu 300 Mbit/s WLAN-Geschwindigkeit, ideal für bandbreitenintensive Anwendungen.
- Unterstützt 4 Betriebsmodi: Router-, Access Point-, Repeater- und WISP-Modus
- Zugriffsbeschränkung für effektiven Jugendschutz
- IPTV unterstützt GMP Proxy/Snooping, Bridge und Tag VLAN zur Optimierung des IPTV Streaming
- Kompatibel mit IPv6 (Internet Protocol Version 6)
- Gastnetzwerk zur Sicherstellung Ihres Internetzugangs
| WLAN | |
|---|---|
| Standards |
Wi-Fi 4 IEEE 802.11n/b/g 2.4 GHz |
| WiFi Speeds |
N300 2.4 GHz: 300 Mbps (802.11n) |
| WiFi Range |
2 Bedroom Houses
2× Fixed Antennas |
| WiFi Capacity | Legacy |
| Working Modes |
Router Mode Access Point Mode Range Extender Mode WISP Mode |
| HARDWARE | |
|---|---|
| Processor | Single-Core CPU |
| Ethernet Ports |
1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports |
| Buttons | Reset Button |
| Power | 9 V ⎓ 0.6 A |
| SICHERHEIT | |
|---|---|
| WiFi Encryption |
WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) |
| Network Security |
SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
| Guest Network | 1× 2.4 GHz Guest Network |
| SOFTWARE | |
|---|---|
| Protocols |
IPv4 IPv6 |
| Parental Controls |
URL Filtering Time Controls |
| WAN Types |
Dynamic IP Static IP PPPoE PPTP L2TP |
| Quality of Service | QoS by Device |
| NAT Forwarding |
Port Forwarding Port Triggering DMZ UPnP |
| IPTV |
IGMP Proxy IGMP Snooping |
| DHCP |
Address Reservation DHCP Client List Server |
| DDNS |
NO-IP Comex DynDNS |
| Management |
Tether App Webpage Check Web Emulator> |
| OTHER | |
|---|---|
| System Requirements |
Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
| Certifications | FCC, CE, RoHS |
| Environment |
Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
| TEST DATA | |
|---|---|
| WiFi Transmission Power |
CE: <20dBm(2.4GHz) FCC: <30dBm |
| WiFi Reception Sensitivity |
270M: -68dBm@10% PER 130M: -68dBm@10% PER 108M: -68dBm@10% PER 54M: -68dBm@10% PER 11M: -85dBm@8% PER 6M: -88dBm@10% PER 1M: -90dBm@8% PER |
| PHYSICAL | |
|---|---|
| Dimensions (W×D×H) |
7.2 × 5.0 × 1.4 in (182 × 128 × 35 mm) |
| Package Contents |
Wi-Fi Router TL-WR840N Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
