TP-Link JetStream 8-Port-Gigabit-Smart-Switch TL-SG2008P mit 4 PoE+-Ports

111.99 €

Preis inkl. 19.00% MwSt. zzgl. Versand

Artikelnummer: 20040200

GTIN: 6935364072957

Hersteller: TP-Link

Herstellernummer: TL-SG2008P

Im Sortiment seit 28.06.2022

Beschreibung

58W PoE-Leistung: 4× IEEE802.3at/af-konforme PoE+ Ports mit einer Gesamtleistung von bis zu 62 W*.
Alles Gigabit Ports: 4× Gigabit-PoE+Ports und 4× nicht-PoE-Gigabit-Ports ermöglichen Hochgeschwindigkeitsverbindungen
Im Omada-SDN integriert: Zero-Touch Provisionierung(ZTP)**, zentralisiertes Cloud-Management und intelligengentes Monitoring.
Zentralisiertes Management: Der Cloudzugriff und die Omada-App ermöglichen eine sehr konfortable, einfache Verwaltung.
Solide Sicherheitsstrategien: IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, und vieles mehr.
Optimierte Voice- und Video-Anwendungen: L2/L3/L4 QoS und IGMP snooping.

HARDWARE-FUNKTIONEN
Standards und Protokolle	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x
Schnittstelle	• 8× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3at/af PoE+) • Auto-Negotiation/Auto MDI/MDIX
Kabel	• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) • 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
Anzahl Lüfter	Fanless
Spannungsversorgung	• External Power Adapter (Output: 53.5 VDC/ 1.31 A)
Energieverbrauch	• 7.9 W (220 V/50 Hz) (no PD connected) • 79.2 W (220 V/50 Hz) (with 62 W PD connected)
PoE-Ports	• Standard: 802.3af/at compliant • PoE Ports: 4 Ports • Power Supply: 62 W*
Abmessungen (BTH)	8.2 x 4.9 x 1.0 in (209 x 126 x 26mm)

PERFORMANCE
Switchingkapazität	16 Gbps
MAC-Adresstabelle	8k
Paketpufferspeicher	4.1 Mbit
Jumbo-Frames	9 KB

SOFTWARE-FUNKTIONEN
Quality of Service	• 802.1p CoS/DSCP priority • 8 priority queues • Priority Schedule Mode SP (Strict Priority) WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control Port/Flow-based Rating Limit • Smoother Performance • Storm Control Multiple Control Modes(kbps/ratio) Broadcast/Multicast/Unknown-Unicast Control
Layer2- und Layer2+-Funktionen	• DHCP Relay DHCP VLAN Relay • DHCP L2 Relay • Link Aggregation Static link aggregation 802.3ad LACP Up to 8 aggregation groups and up to 8 ports per group • Spanning Tree Protocol 802.1D STP 802.1w RSTP 802.1s MSTP STP Security: TC Protect, BPDU Filter/Protect, Root Protect • Loopback Detection • Flow Control 802.3x Flow Control • Mirroring Port Mirroring CPU Mirroring One-to-One Many-to-One Flow-Based Ingress/Egress/Both • Device Link Detect Protocol (DLDP) • 802.1ab LLDP/ LLDP-MED
Layer2-Multicast	• 511 IPv4, IPv6 shared multicast groups • IGMP Snooping IGMP v1/v2/v3 Snooping Fast Leave IGMP Snooping Querier Static Group Config • Multicast VLAN Registration (MVR) • Multicast Filtering • MLD Snooping MLD v1/v2 Snooping Fast Leave MLD Snooping Querier Static Group Config • Limited IP Multicast (256 profiles and 16 entries per profile)
IPv6 Support	• IPv6 Dual IPv4/IPv6 • Multicast Listener Discovery (MLD) Snooping • IPv6 neighbor discovery (ND) • Path maximum transmission unit (MTU) discovery • Internet Control Message Protocol (ICMP) version 6 • TCPv6/UDPv6 • IPv6 applications DHCPv6 Client Ping6 Tracert6 Telnet (v6) IPv6 SNMP IPv6 SSH IPv6 SSL Http/Https IPv6 TFTP
VLAN	• VLAN Group Max. 4K VLAN Groups • 802.1Q tag VLAN • MAC VLAN • Protocol VLAN • GVRP • Voice VLAN
Zugriffskontrollliste	• Support up to 230 entries • Time-Range Time Slice Week Time-Range Absolute Time-Range Holiday • Time-based ACL • MAC ACL Source MAC Destination MAC VLAN ID User Priority Ether Type • IP ACL Source IP Destination IP IP Protocol TCP Flag TCP/UDP Source Port TCP/UDP Destination Port DSCP/IP TOS • IPv6 ACL • Combined ACL • Rule Operation Permit/Deny • Policy Action Mirror Rate Limit Redirect QoS Remark • ACL Rules Binding Port Binding VLAN Binding • Actions for flows Mirror (to supported interface) Redirect (to supported interface) Rate Limit QoS Remark
Sicherheit	• AAA • 802.1X Port-based authentication MAC (Host) based authentication Authentication Method includes PAP/EAP-MD5 MAB Guest VLAN Support Radius authentication and accountability • IP/IPv6-MAC Binding 512 Binding Entries DHCP Snooping DHCPv6 Snooping ARP Inspection ND Detection • IP Source Guard 253 Entries Source IP+Source MAC • IPv6 Source Guard 183 Entries Source IPv6 Address+Source MAC • DoS Defend • Static/Dynamic/Permanent Port Security Up to 64 MAC addresses per port • Broadcast/Multicast/Unicast Storm Control kbps/ratio control mode • Port Isolation • Secure web management through HTTPS with SSLv3/TLS 1.2 • Secure Command Line Interface (CLI) management with SSHv1/SSHv2 • IP/Port/MAC-based access control
MIBs	• MIB II (RFC1213) • Bridge MIB (RFC1493) • P/Q-Bridge MIB (RFC2674) • Radius Accounting Client MIB (RFC2620) • Radius Authentication Client MIB (RFC2618) • Remote Ping, Traceroute MIB (RFC2925) • Support TP-Link private MIBs • RMON MIB(RFC1757, rmon 1,2,3,9)

VERWALTUNG
Omada App	Yes
Centralized Management	• Omada Hardware Controller (OC300) • Omada Hardware Controller (OC200) • Omada Software Controller
Cloud Access	Yes (Through OC300, OC200, or Omada Software Controller)
Management Features	• Web-based GUI • Command Line Interface (CLI) through telnet • SNMPv1/v2c/v3 • SNMP Trap/Inform • RMON (1,2,3,9 groups) • SDM Template • DHCP/BOOTP Client • Dual Image, Dual Configuration • CPU Monitoring • Cable Diagnostics • EEE • SNTP • System Log

SONSTIGES
Zertifizierung	CE, FCC, RoHS
Verpackungsinhalt	• TL-SG2008P • Power Adapter • Installation Guide • Rubber Feet
Systemanforderungen	Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10, MAC® OS, NetWare®, UNIX® or Linux.
Umgebung	• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
